Analog Lab and Measurement lab

Everything in the physical world is analog. Our Analog Lab is where we capture those signals—sound, light, and heat—and turn them into data.

The Gear: High-bandwidth oscilloscopes, precision function generators, and low-noise power supplies.

The Goal: To understand the “why” behind the circuit, ensuring signal integrity and efficiency in every design.

LIST OF EQUIPMENT
Sr. Dead Stock No. Name of the Equipment Price
1 DADS/0961/09-10/BEX/08-10 Zener diode Characteristic kit 1511
2 DADS/0961/09-10/BEX/08-11 Single stage CE amplifier 1511
3 DADS/0961/09-10/BEX/08-13 Transistor Characteristic in CB mode 1511
4 DADS/0961/09-10/BEX/08-14 Forward and Reverse bias characteristic of ordinary diode 1511
5 DADS/0961/09-10/BEX/09-15 Two stage RC coupled amplifier 1957
6 DADS/0961/09-10/BEX/09-16 Transistor Characteristics in CE mode 1511
7 DADS/0961/09-10/BEX/09-17 Zener diode as voltage regulator 1511
8 DADS/0961/09-10/BEX/09-18 Study of bridge Rectifier & Filter 1511
9 DADS/0961/09-10/BEX/09-19 Full wave center tap type Rectifier & Filter 1511
10 DADS/0961/09-10/BEX/09-20 Field Effect Transistor 1511
11 DADS/0961/09-10/BEX/09-21 UJT Characteristics 1511
12 DADS/0961/09-10/BEX/09-22 Transistor series Vs Regulator 1511
14 DADS/0961/09-10/BEX/13-52 Astable multivibrator 1760
15 DADS/0961/09-10/BEX/13-53 Bistable multivibrator 1760
16 DADS/0961/09-10/BEX/13-54 Monostable multivibrator 1760
17 DADS/0961/09-10/BEX/13-55 Clipper and Clamper circuit 1760
18 DADS/0961/09-10/BEX/13-56 RC phase shift oscillator 1760
19 DADS/0961/09-10/BEX/13-57 UJT relaxation oscillator 1760
20 DADS/0961/09-10/BEX/13-58 RC integrator and differentiator 1760
21 DADS/0961/09-10/BEX/13-59 Single stage FET amplifier 1760
22 DADS/0961/09-10/BEX/13-60 Voltage series negative feedback amplifier 1760
23 DADS/0961/2008-09/ETC/2-1/A, B, C, D. GOS-620 20MHZ Dual, trace oscilloscope 56800
24 DADS/0961/16-17/ETC/21-112-A, B, C, D Digital storage oscilloscope Islamapur college
25 DADS/0961/2008-09/ETC/2-2/A, B, C, D, E PS302. DC regulated power supply 13777
26 DADS/0961/2009-10/ETC/11-36/A,B,C,D,E Falcon dual channel power supply 27500
27 DADS/0961/2008-09/ETC/2-3/A,B,C,D,E FG 8005B 2 MHz function generator 23110
28 DADS/0961/09-10/BEX/14-71 Inverting amplifier using op-amp 1760
29 DADS/0961/09-10/BEX/14-73 Noninverting amplifier using op-amp 1760
30 DADS/0961/09-10/BEX/14-72 Integrator and differentiator using op-amp 1760
31 DADS/0961/09-10/BEX/14-70 V to I and I to V convertor using op-amp 1760
32 DADS/0961/09-10/BEX/14-68 Summing and Difference amplifier 1760
33 DADS/0961/09-10/BEX/14-69 Zero crossing detector and active peak detector using op-amp 1760
34 DADS/0961/09-10/BEX/14-65 Second order butter worth high pass filter 1760
35 DADS/0961/09-10/BEX/14-67 Band reject filter using op-amp 1760
36 DADS/0961/09-10/BEX/14-66 First order band pass filter using op-amp 1760
37 DADS/0961/09-10/BEX/14-64 Second order butter worth low pass filter using op-amp 1760
38 DADS/0961/09-10/BEX/14-63 Astable multivibrator and VCO using IC 555 1760
39 DADS/0961/09-10/BEX/14-62 Bistable multivibrator and schmitt trigger using IC 555 1760
40 DADS/0961/09-10/BEX/14-61 Monostable multivibrator and Schmitt trigger using IC 555 1760
41 DADS/0961/09-10/IE/07-01 Pressure measurement by using strain gauge 12265.00
42 DADS/0961/09-10/IE/07-02 Calibration of pressure gauge by using dead weight pressure gauge 18844.00
43 DADS/0961/09-10/IE/07-03 Flow rate measurement using Rota meter 13865.00
44 DADS/0961/09-10/IE/07-04 Level measurement using air purge system 16800.00
44 DADS/0961/09-10/IE/07-05 Characteristics of RTD (PT 100) 5057.00
45 DADS/0961/09-10/IE/07-06 Displacement or position measurement using rotary encoder 19555.00
46 DADS/0961/09-10/IE/08-07 Displacement measurement using LVDT 20355.00
47 DADS/0961/09-10/IE/08-08 Humidity measurement or vibration measurement 20355.00
48 DADS/0961/09-10/IE/08-09 Speed measurement using tachometer 14220.00
49 DADS/0961/10-11/CS/91-29 Synchro Transmitter Receiver Pair (CE-6) 19190
50 DADS/0961/10-11/CS/91-30 Analog simulation to study the effect of compensation (CE-27) 13990
51 DADS/0961/10-11/CS/91-31 ON/OFF temperature controller (indicator cum controller) (CE-1) 12690
52 DADS/0961/10-11/CS/91-32 P.I.D controller (microprocessor based) (CE-9) 25980
53 DADS/0961/10-11/IE/85-1 Study of AC phase control 6250.00
54 DADS/0961/10-11/IE/85-2 Study of full wave midpoint converter 6250.00
55 DADS/0961/10-11/IE/85-3 Synchronized UJT firing circuit 7250.00
56 DADS/0961/10-11/IE/85-4 SCR/MOSFET/IGBT/DIAC characteristics part-1 13950.00
57 DADS/0961/10-11/IE/85-6 Light Dimmer 6250.00
TOTAL (Rs. ) 352290/-
